Check valves are extremely simple devices yet they serve an important purpose in many pneumatic circuits.  Generally used in systems where back flow is not permitted, check valves are two-port valves that allow free flow in one direction and block flow in the opposite direction.  They can also be used as a bypass valve, allowing media around components such as needle valves which restrict flow in both directions.

Pneumatic check valves rely on air flow to function and are designed with a specified cracking pressure, which is the minimum pressure required for the valve to operate. Because they are self-automated, pneumatic check valves do not require assistance to open or close and will continue to function without a manual operator, electricity or other external controls. Pneumatic check valves are commonly used in vacuum breakers, steam lines, cooling towers, HVAC system, sump pumps, pressure pumps, boilers and more.

Common uses for check valves include:
Industrial processes including fluid system in chemical and power plants
Aerospace applications including aircraft hydraulic systems
Applications where multiple gases are mixed into a single stream
Irrigation sprinklers and drip irrigation systems
Home heating systems
Rainwater harvesting systems connected to a main water supply
Pneumatic Check Valves for Flow and Bypass Applications

To meet the needs of your application, Pneumadyne manufactures a variety of Check Valves with threaded, barbed and push-to-connect ports.  Our durable valves feature cracking pressures of 0.1 and 0.5 psi to quickly allow flow through the output port.

Features:
Variety of porting options
Low cracking pressure
Electroless nickel plated for corrosion resistance
Durable brass construction
Compact inline or port mounting styles

專業制造、專業服務，KUNAG庫納格為你創造更多價值

不斷提升服務質量，精益求精，“真誠的服務”是KUNAG永恒的主題。庫納格嚴格按照 ISO9001-2000 質量體系認證要求，質量嚴格把關，責任到人，確保生產、銷售、服務的健康運行。加強與用戶溝通，竭誠為廣大客戶提供優質產品，至善至美服務，特此我廠做出如下承諾：

產品標準

產品嚴格按照中國 GB、HG 標準和美國 API 等標準設計、制造、驗收。密封面硬度達到國家規定要求，寬度超過國家標準。

售前服務

產品介紹，技術交流，非標產品設計，疑難解答。

售中服務

守信合同，保證及時供貨，隨時保持與客戶聯系。

對特殊或復雜的產品，我廠安排技術人員對用戶進行產品使用、故障排除、調式及維修進行培訓和指導。

售后服務

KUNAG產品質保期為自出廠起 12 個月，實行“三包”服務(包退、包換、包修)。

產品在使用中我廠定期組織技術、檢查人員進行訪問，征詢用戶對產品質量、使用狀況、改進意見等方面的反饋，以便進一步提高產品質量。

對用戶投訴產品質量問題，快速做出反映，售后服務人員在 24-36 小時(省外 48 小時)趕赴現場。

對售后服務，要求用戶填寫服務后的質量反饋表，并做出鑒定意見，一邊提高嘉德的服務質量。

訂貨流程

座 機 ：021-59718851（AM-8:30 到PM-17:30）

手 機：18918462396（微信同號-24小時服務）

Q   Q：2030185432

郵 箱：[email protected]

收到客戶采購清單，為客戶提供閥門型號選型與報價(價格清單)。

具體商定：交貨期、特殊要求等事宜。

訂貨須知:

客戶對產品有特殊要求，須在訂貨合同中提供以下說明：

（1）結構長度；

（2）連接形式；

（3）公稱直徑、全通徑、縮徑、管道尺寸；

（4）運用介質及溫度、壓力范圍；

（5）實驗、檢驗標準及其他要求；

（6）本場可根據客戶特殊要求配置各類驅動裝置；

如由客戶提供確定的閥門類型和型號時，客戶應正確說明其型號的含義和要求，在供需雙方理解一致的條件下簽訂合同。

聯 系 人：彭工

Q     Q：2030185432

手    機：18918462396 （微信同號-24小時服務）

座    機：021-59718851

E - mail：[email protected]
